| Overview
The Connect Module is a versatile and feature-packed device that connects to various devices seamlessly using Modbus/BACnet in a building automation system. It is designed to interface with various input and output devices, making it ideal for use in a range of applications. With its multiple analog inputs and outputs and its support for BACnet and OWI interfaces, the Connect Module is essential for building automation professionals looking to streamline their workflow and increase efficiency.
| Specifications
- 8 relays. 24V AC/DC, 1A rated
- 8 Universal analog inputs which can take 10K Thermistor/ 0-10V/ 4-20mA inputs
- 4 0-10v or 4-20ma analog outputs
- 4 navigation buttons
- 1.77" 240*128-pixel RGB TFT display
- OWI interface to connect Airoverse sensors
- 24V DC power over RS485 to power 2 wire devices like HyperLite and sensors in future.
- RS485 port for BACnet
- Powers from 24V AC/DC line.
